AMPINVT
Inversor de potencia de onda sinusoidal pura de 3000 W CC y 12 V con cargador de CA
ATENCIÓN:
- Este inversor de potencia puede cargar el banco de baterías cuando la alimentación de CA está conectada al inversor.
- 3000 vatios es potencia de salida continua, la potencia de salida máxima es de 9000 W
- Este inversor puede SOLO Funciona con sistema de batería de 12 V.
- Inversor NO PUEDO Admite conexión en paralelo.
- Inversor DEBE tiene una batería, y la batería DEBE estar conectado primero
Cinco modos de trabajo:
- Modo de prioridad de CA : la entrada de CA (red eléctrica de la ciudad) suministrará energía a la salida de CA (carga del aparato) primero y cargará automáticamente la batería al mismo tiempo. El inversor dejará de cargar automáticamente cuando la batería esté completamente cargada. Cuando no haya entrada de CA, el inversor cambiará automáticamente a la fuente de alimentación de la batería.
- Modo de prioridad de batería : la energía de la batería suministrará energía a la salida de CA (aparatos/carga). Cuando el voltaje de la batería alcanza el límite de voltaje bajo, si la entrada de CA está activada, el inversor cambiará automáticamente al suministro de entrada de CA; si la entrada de CA está desactivada, el inversor se apagará automáticamente. Cuando el voltaje de la batería alcanza el ajuste de restauración de voltaje bajo, el inversor cambiará automáticamente al suministro de batería.
- Modo ECO : similar al modo de prioridad de CA. Cuando la entrada de CA (red eléctrica/red de la ciudad) está apagada, el inversor entrará automáticamente en estado de espera cuando la capacidad de los electrodomésticos sea inferior al 5 % de la capacidad del inversor. El inversor cambiará automáticamente entre el estado encendido y el estado de espera para detectar si la capacidad de salida de CA (electrodomésticos/carga) supera el 5 % de la capacidad del inversor. Si la capacidad de salida de CA supera este límite mencionado anteriormente, el inversor cambiará automáticamente del estado de espera al estado de inversión.
- Modo generador : utiliza un generador inestable para generar energía, accede a la entrada de CA del inversor a través del regulador AVR del inversor, coincidencia automática de frecuencia municipal de 50 HZ/60 HZ, regulador de voltaje de salida en el rango operativo normal.
- Modo sin supervisión : similar al modo de prioridad de CA. Cuando la entrada de CA (red eléctrica/red eléctrica de la ciudad) es demasiado baja, el inversor apagará automáticamente la salida de CA y entrará en estado de ESPERA. Una vez que la batería se haya cargado nuevamente hasta el punto de voltaje de restauración, el inversor reiniciará la salida de CA. Por otro lado, cuando la entrada de CA se vuelva a activar, el inversor también reiniciará automáticamente la salida de CA.
Inverter x1
Power Cable x1
User Manual x1
Communication Wires (optional)
External Display (optional)
Download AMPINVT FT Series Pure Sine Wave inverter Manual
Productos Destacados
We recently purchased and installed the 2000W/12VDC unit for backup of a few critical pieces of equipment.
The inverter is fairly heavy, seems well built (from the outside), and has been up and running now for a few weeks. The documentation is pretty basic, and just gives 'screen shots' of the different menu options.
We have tested with cutting the power (breaker) off to the unit and it promptly switches over to the battery backup without issue (LINE POWER PRIORITY SETTING). We like that there is the option of setting the DC Source as the priority, which would be helpful if you are using solar and want to run off the solar as priority. Of course you are going to need to provide the panels, the wiring and the charge controller to the setup to do this.
We did add in a 'battery monitor' to be able to better 'see' how much power we are using and have remaining off the battery as needed. Would highly recommend this setup to others as the built in components do not seem to be providing accurate numbers (we have a desktop computer, printer a 15w led light and IP phone running off the inverter, and it's stating that we only have a 3% load on the inverter - which cannot be right). We wanted some way to validate the usage on our battery in a 'backup' situation.
All-in-all the unit at this price point does what it should, seems to be well built and operates as expected. We're giving it a solid 4 stars, but holding one back for the output wiring issue and battery monitoring inconsistencies.
I installed this in my school bus conversion and am very pleased with its performance so far. I love how I can hook up everything I need on the 12 volt poles (batteries and loads), hook up 120 volt AC loads on the other side, plug in 120 volt AC from grid power, and this inverter charter keeps track of everything and automatically knows what to do in order to keep the loads going and the battery voltage in acceptable ranges. I even set up a 4-way isolater switch on the 12 volt side to let me select between the bus starter batteries, the lithium phosphate "house batteries", both battery banks at once, or neither bank. When plugged into grid power, I can decide which battery bank I want the inverter to charge. Also, because the bus alternator is wired to the starter batteries, I can set the switch to "1+2" and have the bus engine charging all batteries as well as supplying power to the inverter, which can be used to power the 120 volt AC gear I have in the bus.
This inverter has been able to power a 12,000 BTU mini-split air conditioner, a 13 cubit foot refrigerator, and various handheld power tools. It only beeps at me if I am running more than two of these things at once.
Overall, I love having the charger integrated. I love how this unit does so much and has a lot of modes and options for being in different situations on the road or camped out. Five stars all day long.
A great unit, exactly what I needed for my motorhome. I am a newbie when it comes to dolar systems do it would have been a hugh hrlp if thr manual was more informative. I also purchased the remote panel. Installation was a snap.
I have purchased and have owned 5 Inverters prior to this purchase and it has been surprisingly the best one so far.
Decided to upgrade to an Inveter that has UPS capabilities for our Mobile Food Truck as we have had power being loss when connected to shore during storms at our Storage facility where we park our trucks.
The ATS feature works as expected, load handling is great.
It appears to be well made and quality steel casing. It does a better job of handling power consumption with battery bank which provides longer run time.
I need another unit to replace another Inverter, but this unit and the 24V version is no longer available on Amazon.
Hoping they will bring back.
I bought this inverter for my camper to run the ac power when not connected to shore power, other than shipping damage when I received the product it has performed excellent.
