AMPINVT
Inversor de potencia de onda sinusoidal pura de 3000 W CC y 24 V con cargador de CA
- High transfer efficiency is above 88%, , complete isolate surge interference of input & output's voltage and current, Impact resistance, super load capacity, built-in AVR stabilizer, continuous stable pure sine wave output.
- Battery typesetting choose : SLA / AGM / GEL / Li-ion battery & Customize. Support lifep07，Sealed Gel AGM Flooded Lithium, Sealed, Gel, and Flooded Batteries.
- Adjustable Charging Current: The max charge current can be adjusted from 0%-100%, 100% is max charge current 35A. Setting the value to 0% will turn off the charging function.
- Five working mode : AC priority mode / Battery priority mode / Generator mode / ECO mode / Unattended mode.
- Protections: Battery low voltage alarm / Battery high voltage alarm / Over temperature protection / Over load protection / Short Circuit protection.
Inversor de baja frecuencia Ampinvt 3000W
- Este inversor de onda sinusoidal pura es una combinación de inversor, cargador de batería e interruptor de transferencia automática de CA. La alta eficiencia de transferencia es superior al 90 %, aísla completamente la interferencia de sobretensiones de entrada y salida de voltaje y corriente, es resistente a impactos, tiene una gran capacidad de carga, estabilizador AVR integrado y salida de onda sinusoidal pura estable y continua.
- Configuración del tipo de batería: SLA/AGM/GEL/batería de ion de litio y personalización. Admite baterías de litio inundadas, selladas, de gel y inundadas LifeP04 AGM.
- Corriente de carga ajustable: la corriente de carga máxima se puede ajustar de 0 % a 100 %; el 100 % es la corriente de carga máxima de 35 A. Si se establece el valor en 0 %, se desactivará la función de carga.
- Protecciones: Alarma de bajo voltaje de batería / Alarma de alto voltaje de batería / Protección contra sobretemperatura / Protección contra sobrecarga / Protección contra cortocircuito. El 110%-120% de la salida se mantuvo durante 30 s, luego la salida pasó a derivación, más del 160% mantuvo los 300 ms.
ATENCIÓN:
- Este inversor de potencia puede cargar el banco de baterías cuando la alimentación de CA está conectada al inversor.
- 3000 vatios es potencia de salida continua, la potencia de salida máxima es de 9000 W
- Este inversor puede SOLO Trabajar con sistema de batería de 24 V.
- Inversor NO PUEDO Admite conexión en paralelo.
- Inversor DEBE tiene una batería, y la batería DEBE estar conectado primero
CINCO MODOS DE TRABAJO:
- Modo de prioridad de CA - La entrada de CA (red eléctrica de la ciudad) suministrará energía a la salida de CA (carga del aparato) primero y cargará automáticamente la batería al mismo tiempo. El inversor dejará de cargar automáticamente cuando la batería esté completamente cargada. Cuando no haya entrada de CA, el inversor cambiará automáticamente a la fuente de alimentación de la batería.
- Modo de prioridad de batería - La energía de la batería suministrará energía a la salida de CA (aparatos/carga). Cuando el voltaje de la batería alcance el límite de voltaje bajo, si la entrada de CA está activada, el inversor cambiará automáticamente al suministro de entrada de CA; si la entrada de CA está desactivada, el inversor se apagará automáticamente. Cuando el voltaje de la batería alcance el ajuste de restauración de voltaje bajo, el inversor cambiará automáticamente de nuevo al suministro de batería.
- Modo ecologico - Similar al modo de prioridad de CA. Cuando la entrada de CA (red eléctrica/red urbana) está apagada, el inversor entrará automáticamente en estado de espera cuando la capacidad de los electrodomésticos sea inferior al 5 % de la capacidad del inversor. El inversor cambiará automáticamente entre el estado encendido y el estado de espera para detectar si la capacidad de salida de CA (electrodomésticos/carga) supera el 5 % de la capacidad del inversor. Si la capacidad de salida de CA supera este límite mencionado anteriormente, el inversor cambiará automáticamente del estado de espera al estado de inversión.
- Modo generador - utilice un generador inestable para generar energía, acceda a la entrada de CA del inversor a través del regulador AVR del inversor, ajuste automático de la frecuencia municipal de 50 HZ/60 HZ, regulador de voltaje de salida en el rango operativo normal.
- Modo desatendido - Modo de prioridad de CA similar. Cuando la entrada de CA (red eléctrica/red urbana) es demasiado baja, el inversor apagará automáticamente la salida de CA y entrará en estado de ESPERA. Una vez que la batería se haya cargado nuevamente hasta el punto de voltaje de restauración, el inversor reiniciará la salida de CA. Por otro lado, cuando la entrada de CA se vuelva a activar, el inversor también reiniciará automáticamente la salida de CA.
Inverter x1
Power Cable x1
User Manual x1
Communication Wires (optional)
External Display (optional)
Download AMPINVT FT Series Inverter Charger Manual
Productos Destacados
i got charge controlers and inverters charge controlers are the best inverters i have had lots still have 3000 ampinvt working every day first one i got still going got a 5000 i blew up chargeing a ev if you charge ev unit needs more cooling i put fan on it helps alot ampinvt has all partes in stock to fix it they are great inverters but if you run at 95% add a fan to help it stay cool you need large battery or unit can switch back and forth from charge to grid it all has to be correct and unit works great very powerful its the best i sure will get better need 48 volt 10000 watt to the line up just inverter plan what i like see with low price thanks jock buy them they work great
We recently purchased and installed the 2000W/12VDC unit for backup of a few critical pieces of equipment.
The inverter is fairly heavy, seems well built (from the outside), and has been up and running now for a few weeks. The documentation is pretty basic, and just gives 'screen shots' of the different menu options.
We have tested with cutting the power (breaker) off to the unit and it promptly switches over to the battery backup without issue (LINE POWER PRIORITY SETTING). We like that there is the option of setting the DC Source as the priority, which would be helpful if you are using solar and want to run off the solar as priority. Of course you are going to need to provide the panels, the wiring and the charge controller to the setup to do this.
We did add in a 'battery monitor' to be able to better 'see' how much power we are using and have remaining off the battery as needed. Would highly recommend this setup to others as the built in components do not seem to be providing accurate numbers (we have a desktop computer, printer a 15w led light and IP phone running off the inverter, and it's stating that we only have a 3% load on the inverter - which cannot be right). We wanted some way to validate the usage on our battery in a 'backup' situation.
All-in-all the unit at this price point does what it should, seems to be well built and operates as expected. We're giving it a solid 4 stars, but holding one back for the output wiring issue and battery monitoring inconsistencies.
I installed this in my school bus conversion and am very pleased with its performance so far. I love how I can hook up everything I need on the 12 volt poles (batteries and loads), hook up 120 volt AC loads on the other side, plug in 120 volt AC from grid power, and this inverter charter keeps track of everything and automatically knows what to do in order to keep the loads going and the battery voltage in acceptable ranges. I even set up a 4-way isolater switch on the 12 volt side to let me select between the bus starter batteries, the lithium phosphate "house batteries", both battery banks at once, or neither bank. When plugged into grid power, I can decide which battery bank I want the inverter to charge. Also, because the bus alternator is wired to the starter batteries, I can set the switch to "1+2" and have the bus engine charging all batteries as well as supplying power to the inverter, which can be used to power the 120 volt AC gear I have in the bus.
This inverter has been able to power a 12,000 BTU mini-split air conditioner, a 13 cubit foot refrigerator, and various handheld power tools. It only beeps at me if I am running more than two of these things at once.
Overall, I love having the charger integrated. I love how this unit does so much and has a lot of modes and options for being in different situations on the road or camped out. Five stars all day long.
A great unit, exactly what I needed for my motorhome. I am a newbie when it comes to dolar systems do it would have been a hugh hrlp if thr manual was more informative. I also purchased the remote panel. Installation was a snap.
I have purchased and have owned 5 Inverters prior to this purchase and it has been surprisingly the best one so far.
Decided to upgrade to an Inveter that has UPS capabilities for our Mobile Food Truck as we have had power being loss when connected to shore during storms at our Storage facility where we park our trucks.
The ATS feature works as expected, load handling is great.
It appears to be well made and quality steel casing. It does a better job of handling power consumption with battery bank which provides longer run time.
I need another unit to replace another Inverter, but this unit and the 24V version is no longer available on Amazon.
Hoping they will bring back.
